Detection, Interference, Deception and Protocol Analysis Integrated Equipment

Performance parameters：

1. Detection frequency band: 300MHz~6GHz. Instantaneous detection bandwidth: not less than 200MHz. Detection and alarm distance: Under line-of-sight conditions, the omnidirectional detection and alarm distance for UAV downlink signals is not less than 2km (in urban outdoor environment; UAV downlink signal transmission power is not less than 100mW) Wide-band adjustable interference signal generation capability: capable of generating interference signals at any frequency between 300MHz and 6GHz as needed, with an equivalent radiation power of not less than 10W and a maximum instantaneous interference bandwidth of not less than 200MHz. 2. UAV satellite navigation and positioning terminal interference signal generation capability Navigation suppression interference signal generation capability: capable of simultaneously generating navigation suppression interference signals for the 1160MHz ~ 1300MHz and 1550 ~ 1650MHz frequency bands. Navigation deception signal generation capability: capable of transmitting navigation deception signals covering GPS L1, Beidou B1, Galileo E1, and GLONASS L1 frequencies. 3. Interference to drone remote control link interference ratio: not less than 2:1 (the assessment objects include at least ""DJI"" Mini 4 Pro drones and ""Daotong"" EVO Lite drones). Suppression and interference distance for UAV satellite navigation and positioning terminals: no less than 1.5km (with DJI Mini 4 Pro UAV as the assessment object)
